PCIe 4.0 speed maximizedHuge speed boost, faster random read/write speeds than 980. Fly high in gaming, video and 3D editing, data analysis, and more.Breakthrough power efficiencyMore power-efficient performance. Higher performance usually consumes more power. 990 PRO uses less power with up to 50% improved performance per watt over 980 PRO. This low-power design makes max PCIe 4.0 performance possible with optimal power efficiency.Smart thermal solutionSink that heat. The slim heatsink dissipates heat to prevent performance drops from overheating. Get stable heat control, and minimal fan noise for heavy-graphic gaming. The thin body is compatible with PlayStation 5, desktops, and laptops meeting the PCI-SIG D8 standard.The champion makerThe best gameplay experience. A more than 55% improvement in random performance enables faster loads for ultimate gaming realism on PS5 and DirectStorage PC games. The heatsink's futuristic design adds style to heat control, now with RGB lights.
Спецификации
- ManufacturerSAMSUNG
- Manufacturer Part NoMZ-V9P1T0CW
- Device TypeSolid state drive - internal
- NAND Flash Memory TypeMulti-level cell (MLC)
- InterfacePCIe 4.0 x4 (NVMe)
- Features1 GB Low Power DDR4 SDRAM Cache, Samsung V-NAND 3bit MLC Technology, Auto Garbage Collection Algorithm, Dynamic Thermal Guard protection, sleep mode, PS5 compatible, NVMe 2.0, S.M.A.R.T.
- Width24.3 mm
- Depth80 mm
- Height8.2 mm
- Weight28 g
- Internal Data Rate7450 MBps (read) / 6900 MBps (write)
- MTBF1,500,000 hours
- InterfacesPCI Express 4.0 x4 (NVMe)
- Compatible BayM.2 2280
- Power Consumption5.4 watt (read) 5 watt (write) 50 mW (idle) 5 mW (L1.2 mode)
- Service & SupportLimited warranty - 5 years / 600 TBW
- Min Operating Temperature0 °C
- Max Operating Temperature70 °C
- Min Storage Temperature-40 °C
- Max Storage Temperature85 °C
- Vibration Tolerance (non-operating)20 g @ 20-2000 Hz
- Warranty60 months
- EAN8806094413748
- Capacity1 TB
- Form FactorM.2 2280
- Software IncludedSamsung Magician Software
- Shock Tolerance (non-operating)1500 g
- Encryption Algorithm256-bit AES
- Package DetailsBox
- Humidity Range Operating5 - 95% (non-condensing)
- Hardware EncryptionYes
- Integrated HeatsinkYes
- Compliant StandardsIEEE 1667
- Maximum 4KB Random Write1550000 IOPS
- Maximum 4KB Random Read1200000 IOPS
