Reliable connectivityEquipped with a wireless cellular modem, the RUT241 delivers a maximum transfer rate of 150 Mbps, ensuring efficient data transfer and reliable connectivity.Flexible managementThe router provides various remote management protocols such as SNMP, HTTP, and HTTPS, allowing for easy monitoring and configuration from remote locations.Enhanced securityWith encryption algorithms such as AES-CCMP and WPA2-Enterprise, the RUT241 offers robust security measures to safeguard data and limit unauthorized access.Environmental resilienceThe device is compliant with IP30 standards, ensuring protection against dust and solid objects, while also being designed to withstand extreme temperatures.User-friendly featuresThe RUT241 includes features like DHCP relay and captive portal, enhancing usability for network management and user access control.
Спецификации
- ManufacturerTELTONIKA NETWORKS
- Manufacturer Part NoRUT241000000
- Device TypeWireless router
- Enclosure TypeDesktop, DIN rail mountable
- Connectivity TechnologyWired, wireless
- Data Link ProtocolIEEE 802.11b, IEEE 802.11g, IEEE 802.11n, Ethernet, Fast Ethernet
- Network / Transport ProtocolTCP/IP, UDP/IP, IPv4, IPv6, NTP, DNS, HTTP, HTTPs, FTP, SMTP, ARP, PPPoE, DHCP, Telnet, DDNS, OpenVPN, L2TP, PPTP, WireGuard
- Encryption AlgorithmWPA2-Enterprise, PEAP, WPA2-PSK, WEP, WPA-EAP, WPA-PSK, AES-CCMP, TKIP, SSL 3.0, TLS, DES, RC2, Blowfish, CAST5, 128-bit AES, 256-bit AES, 192-bit AES, IKEv1, IKEv2, 3DES, MODBUS
- FeaturesSMS alert, white list, black list, band management, auto APN, bridge mode, software access point, client separation, Auto Cipher modes, Stealth Mode, MACsec, Captive Portal, auto-uplink (auto MDI/MDI-X), PPP, Telnet client, WOL, VoIP passthrough support, connection monitoring, DHCP relay, QoS, load balancing, PSK, digital certificates, DDoS Protection, VLAN support, mobile quota control, MAC address filtering, GRE tunneling, FOTA, Teltonika RMS, reset key, aluminium housing, WAN failover
- Compliant StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, UPnP, IP30, RED, UKCA, EN 301 489-1 V2.2.3, EN 301 489-17 V3.2.4 (2020-09), EN 301 489-52 V1.2.0, EN 55032:2015+A1:2020, EN 55035:2017+A11:2020, EN 61000-3-3:2013+A1:2019, EN IEC 61000-3-2:2019, EN 61000-4-2:2009, EN 61000-4-3:2020, EN 61000-4-4:2012, EN 61000-4-5:2014+A1:2017, EN 61000-4-6:2014, EN IEC 61000-4-11:2020, EN 300 328 V2.2.2, EN 301 511 V12.5.1, EN 301 908-1 V13.1.1, EN 301 908-2 V13.1.1, EN 301 908-13 V13.1.1, EN IEC 62311:2020, EN 50665:2017, EN IEC 62368-1:2020+A11:2020, IEC 62368-1:2018
- Status IndicatorsPower, status, signal strength
- Mobile Communication ProtocolFDD LTE
- InterfacesLAN: 1 x 10Base-T/100Base-TX - RJ-45 WAN: 1 x 10Base-T/100Base-TX - RJ-45 Antenna: 2 x SMA Antenna: 1 x RP-SMA 1 x DI 1 x DO
- Expansion Slots1 (total) / 1 (free) x Mini-SIM
- AerialExternal detachable
- Antenna Qty3
- Power DeviceExternal power adapter
- Width8.3 cm
- Depth7.4 cm
- Height2.5 cm
- Weight125 g
- Min Operating Temperature-40 °C
- Max Operating Temperature75 °C
- Humidity Range Operating10 - 90% (non-condensing)
- Warranty24 months
- Frequency Band2.4 GHz
- Routing ProtocolBGP, OSPFv2, RIP-2, RIP-1, RIPng, OSPF for IPv6, VRRP
- Remote Management ProtocolICMP, SSH, SNMP, MQTT, TR-069, SNMP 1, SNMP 2, SNMP 3, HTTP, HTTPS, JSON, Modbus
- Authentication MethodRADIUS, X.509 certificates
- Voltage RequiredDC 9 - 30 V
- Power Consumption Operational6.5 watt
- OS ProvidedRutOS
- Generation2G, 3G, 4G
- Cellular BandLTE B1, LTE B20, LTE B28A, LTE B3, LTE B7, LTE B8
- Max Transfer Rate150 Mbps
- LocalisationEurope
- CapacitySimultaneous connections: 50 IPSec VPN tunnels: 4
- Processor1 x MediaTek MIPS 24KC 580 MHz
- Cables Included1 x network cable - 1.5 m
- Included AccessoriesSIM card adapter kit, WiFi aerial, 2 x LTE aerials
- Internet of Things (IoT) CompatibleYes
- Shipping Width17.3 cm
- Shipping Depth14.8 cm
- Shipping Height7.1 cm
- Software IncludedZeroTier VPN
