Robust securityEquipped with a suite of encryption algorithms including 256-bit AES-GCM, Triple DES, and SHA-2, the Cisco Catalyst 8200L-1N-4T ensures robust security for all data transactions. Its comprehensive security features safeguard against a wide range of threats, making it an ideal choice for organizations prioritizing data protection.High performanceWith an IPv4 forwarding throughput of 3.8 Gbps and SD-WAN IPsec throughput of up to 500 Mbps, this router is designed to handle high-volume traffic efficiently. Its performance capabilities support a seamless and reliable network experience, even in demanding environments.Advanced networkingFeaturing support for a wide array of protocols and services including BGP, OSPF, and Quality of Service (QoS), the Cisco Catalyst 8200L-1N-4T facilitates sophisticated network architectures. Its ability to manage complex routing and networking tasks makes it a versatile backbone for any enterprise network.Scalable capacityWith capacity for up to 1,500 SD-WAN overlay tunnels, 800,000 IPv4 routes, and 512,000 firewall sessions, this router is built to scale with your business. Its expansive capabilities ensure that growing network demands are met without the need for frequent hardware upgrades.Reliable designA Mean Time Between Failures (MTBF) of 692,577 hours underscores the reliability of the Cisco Catalyst 8200L-1N-4T. Its robust design and built-in redundancy features minimize downtime, ensuring continuous operation and peace of mind for businesses.
Спецификации
- ManufacturerCISCO
- Manufacturer Part NoC8200L-1N-4T
- Device TypeRouter
- Enclosure TypeRack-mountable - 1U
- Connectivity TechnologyWired
- Data Link ProtocolGigabit Ethernet
- Network / Transport ProtocolIPSec, NTP, DNS, DHCP, RSVP, RTCP, PPPoE, L2TPv3
- Encryption AlgorithmPKI, 256-bit AES-CBC, 256-bit AES-GCM, IKE, 2048-bit RSA, ECDSA 256-bit, ECDSA 384-bit, ESP, HMAC, SHA-1, SHA-2, TLS, DES, 1024-bit RSA, 128-bit AES, 256-bit SHA, 384-bit SHA, 512-bit SHA, 748-bit RSA, MD5, Triple DES
- FeaturesURL filtering, AAA, QoS, CoS, FEC, HQoS, WRED, FNF, NBAR, AAR, DTLS, DHCP client, DHCP server, Syslog support, NAT support, PAT support, ACL support, BFD, CAC, IVR, SAF, CBWFQ, HDLC, MLFR, MLPPP, PPP, PIM, SSM, ERSPAN, Cisco IPSLA, EEM, EVC, AVC, SUDI
- Compliant StandardsIEEE 802.1Q, IEEE 802.1ag, IEEE 802.3ah, UL 60950-1, CAN/CSA C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1, IEC/EN 60825, FDA, FCC CFR47 Part 15 A, ICES-003 Class A, AS/NZS CISPR 32 Class A, CISPR 32 Class A, VCCI-CISPR 32:2016 Class A, CNS 13438 Class A, EN 61000-3-2, IEC 61000-3-2, KN32 Class A, IEC/EN 61000-3-3, EN 300 386, EN 55032, EN 55035, EN 61000-6-1, EN55024, IEC/EN 61000-4-11, IEC/EN 61000-4-2, IEC/EN 61000-4-3, IEC/EN 61000-4-4, IEC/EN 61000-4-5, IEC/EN 61000-4-6, IEC/EN 61000-4-8, KN35, SIG
- InterfacesWAN: 2 x Ethernet 1000 - SFP (mini-GBIC) WAN: 2 x Ethernet 1000 - RJ-45
- Expansion Slots1 (total) / 1 (free) x NIM 1 (total) / 1 (free) x Pluggable Interface Module (PIM)
- Power DeviceInternal power supply - 100 watt
- Width43.8 cm
- Depth30 cm
- Height4.39 cm
- Weight4.54 kg
- Min Operating Temperature0 °C
- Max Operating Temperature40 °C
- Humidity Range Operating5 - 85% (non-condensing)
- Warranty12 months
- OS RequiredCisco IOS XE 17.5.1
- PerformanceSD-WAN IPsec throughput (1400Bytes, clear text): 500 Mbps SD-WAN IPsec throughput (IMIX, clear text): 400 Mbps IPv4 forwarding throughput (1400-byte packet size): 3.8 Gbps IPsec throughput (1400Bytes, clear text): 500 Mbps
- Routing ProtocolPolicy-based routing (PBR), GRE, OSPF, BGP, VRRP, MPLS, OSPFv3, RIP, RIP-2, EIGRP, IS-IS, IGMPv3, HSRP, DVMRP, Bidirectional Forwarding Detection (BFD)
- Remote Management ProtocolOMP, SNMP, SCP
- Authentication MethodSecure Shell (SSH), RADIUS
- Voltage RequiredAC 120/230 V (50/60 Hz)
- CapacitySD-WAN overlay tunnels scale: 1500 IPsec SVTI tunnels: 1500 Access Control Entries (ACEs) per system (IPv4): 72000 IPv4 routes: 800000 IPv6 routes: 800000 Queues: 16000 NAT sessions: 600000 Firewall sessions: 512000 Virtual Routing and Forwarding (VRF) entries: 2000 ACLs per system: 4000
- ProcessorIntel
- Built-in Devices16 GB SSD
