Спецификации

CPU model
AMD Ryzen AI 5 340, 6 Cores / 12 Threads, Up to 4.8 GHz, 22 MB Total Cache, NPU (Up to) 50 TOPS
I/O
Front: 2 × USB 3.2 Gen 2 Type-A, 1 × 3.5 mm Audio Jack; Rear: 2 × USB4 Type-C, 1 × USB 3.2 Gen 2 Type-A, 1 × USB 2.0 Type-A, 2 × HDMI 2.1, 1 × RJ-45, 1 × DC-In
Color
Black / Gold
Power supply
External 120 W Power Adapter; 19 V DC / 6.32 A
Audio
Realtek ALC256; 3.5 mm Audio Jack; HDMI / USB-C Digital Audio
Security
Kensington Security Lock Slot
Mechanical design
Compact Mini PC; Active Cooling; VESA Mounting Support
Power
CPU Default TDP: 28 W
Vendor_url
https://www.sapphiretech.com/en/commercial/edge-ai-mini-pc#Specification
Model
EDGE AI 340
Memory size
No RAM Installed; Up to 96 GB Supported
Graphics
Integrated AMD Radeon 840M Graphics
Disk specifications
PCIe NVMe SSD Support
Interfaces/Ports
USB4 40 Gbps; USB 3.2 Gen 2 10 Gbps; USB 2.0; HDMI 2.1; 2.5GbE LAN; 3.5 mm Audio
Expansion slots
1 × M.2 2280 PCIe 4.0 x4; 1 × M.2 2242 PCIe 4.0 x4; 1 × M.2 2230 Key E (Occupied by Wireless Module)
Wireless
Wi-Fi 6E (802.11ax)
Dimensions
117 × 111 × 30 mm (W × D × H)
Part number / Product code
4H020-06-40G
Mainboard
Proprietary Mini PC Mainboard; AMD FP8 Platform
Memory
2 × DDR5 SO-DIMM Slots; Dual Channel; Up to 96 GB (2 × 48 GB)
Storage
1 × M.2 2280 PCIe 4.0 x4; 1 × M.2 2242 PCIe 4.0 x4
Display
Supports Up to 4 External Displays
