Спецификации
- Физически ядра8-core
- Честота, GHz4 GHz
- Кеш, MB96 MB
- СокетSocket AM5
- Графичен ускорителRadeon Graphics
- ManufacturerAMD
- Manufacturer Part No100-100002235WOF
- Product TypeProcessor
- Type / Form FactorAMD Ryzen 7 7700X3D
- Number of Threads16 threads
- Cache Memory DetailsL3 - 96 MB L2 - 8 MB L1 - 512 KB
- Processor Qty1
- Max Turbo Speed4.5 GHz
- Manufacturing Process5 nm
- Thermal Design Power120 W
- Thermal Specification89 °C
- PCI Express Revision5.0
- PCI Express Lanes Qty28
- Architecture Features"Zen 4" Core Architecture, AMD Simultaneous Multithreading (SMT)
- Package TypeAMD Processor in a Box (PIB)
- Warranty36 months
- EAN730143318488
- Base Frequency2200 MHz
- Vendor_urlhttps://www.amd.com/en/products/processors/desktops/ryzen/7000-series/amd-ryzen-7-7700x3d.html
- SocketAM5
- Threads16
- FrequencyMax. Boost Clock: Up to 4.5 GHz; Base Clock: 4 GHz
- Max. PCI Express Lanes28 , 24 (Total/Usable)
- Memory specificationSystem Memory Type: DDR5; Memory Channels: 2; Max. Memory: 128 GB; System Memory Subtype: UDIMM; Max Memory Speed:; 2x1R DDR5-5200; 2x2R DDR5-5200; 4x1R DDR5-3600; 4x2R DDR5-3600; ECC Support: Yes (Requires mobo support)
- GraphicsAMD Radeon™ Graphics, Core Count: 2, 2200 MHz; DisplayPort™ Alternate Mode: Yes
